  • Walk Through Metal Detector SE1806S Of 18 Zones
  • Walk Through Metal Detector SE1806S Of 18 Zones
Walk Through Metal Detector SE1806S Of 18 ZonesWalk Through Metal Detector SE1806S Of 18 Zones

Walk Through Metal Detector SE1806S Of 18 Zones

Features Of Walk Through Metal Detector SE1806S

1. Superior target detection with unmatched discrimination of harmless items such as coins, jewelry, keys, cigarette packs, etc.

2. The ultimate in safety, throughput and reliability with preset programs to cover the most complete range of security applications including the new Enhanced Metal Detector (EMD) required for all airport installations.

3. Multi-dimensional coil design (18 distinct pinpoint zones) provides superior detection and location of guns, knives and other flat and rod-shaped weapons regardless of orientation.

4. Circuitry with advanced Digital Signal Processor (DSP) technology locates even small, hard-to-find, floor level weapons.

5. Individual zone boost adjustments allow for customization of detection characteristics and/or compensation for metallic environmental challenges.

6. Durable, IP 55 weather-proof construction.

7. Can be connected to the PC for the comunication .

8. With REMOTE Control

9. Have the interface for the CCTV, Monitorn

Specifications Of Walk Through Metal Detector SE1806S:

· Operating Temperatures
-4°F (-20°C) to + 158°F (70°C); Humidity: To 95% non-condensing

· Power
Fully automatic 100 to 240 VAC, 50 or 60 Hertz, 5 watts; no rewiring, switching or adjustments required. Power supply meets UL, CE,FCC standards.

· Weatherproofing / Foreign Object Protection Standards

· Tamper-Proof
All settings are secured with a key lock and two levels of access codes. Further security is accomplished with a cabinet lock which prevents unauthorized access to physical cables, connectors and electronics.

· Construction
Attractive scratch and mar-resistant laminate. Detection Heads and Support: Heavy duty aluminum.

· Control Outputs
Solid state switches (low voltage AC or DC) for operating external alarms and control devices.

· Traffic Counter
Counter tracks the number of patrons that have passed through the detector, the number of alarms and calculates alarm percentage.

· Synchronization
Dual channels and DSP circuitry allow several ZA-1800S's to operate simultaneously in close proximity to one another.

· Interference Suppression
Special DSP built-in circuitry eliminates effects from x-ray monitors and other potential electrical interference sources.

· Alarms
Audible tone and volume adjustable. Bright LED visual alarm.

· Target Pinpointing Lights
18 distinct zones are displayed with 2 independent columns of LED's located on exit side of ZA-1800S.

· Pacing Lights
International symbols

· Warranty
Limited 24 months, parts and labor

Technical Parameters

Power Supply

220V/AC 110V/AC



External Dimension


Passageway Dimension


Work environment

-20°C- +45°C



Standard configuration

Main Case


Left Probe


Right Probe


Power Line





ONE (Including one Certificate of Quality & Guarantee Repair List)


Main Case

0.755m*0.485m*0.255m (Carton)



Total Volume



50kg (Approx.)

Application Of Walk Through Metal Detector SE1806S

·Airports and Seaports

·Government Buildings


·Police Facilities


·Prisons and jails

·Military Bases



·Financial Institutions

·Colleges and Schools

·Hotels and Casinos

·Power plants

·Research Sites

·Sports Stadiums

·Public Transportation

·Public Landmarks

·Factories and Warehouses

·Broadcast Studios


·Night Clubs
