  • Walk Through Metal Detector SE1800T Of 18 Zones

Walk Through Metal Detector SE1800T Of 18 Zones

Product Details Of Walk Through Metal Detector SE1800T

General Specifications
Outer frame
2220mm (H) x820mm(W)x500mm(D)
Inner frame
2000mm (H)x700mm(W)x500mm(D)
Electrical current
AC100V~240V 50/60Hz
Unit weight
Signal Frequency
Work environment
-20C to +45C
Sensitivity adjustable
Level 0-299
Sound and light
Max distance
0.3m at low sensitivity;0.5m at high sensitivity
Master control board
Metal-detect-door-main bd
Digital keypad
REV120 A&C door panel board
Digital display location board
REV030 A&C door zone board
Light bar
REV030 Long bar : metal-detect-door-ledbd
V040 Loudspeaker,8Ω2W,Black,75mmx32mmx27mm
Operation way
Remote control only
With the highest sensibility, it can detect the metal Article as small as the clip.With the range of 0-100, it can be adjusted the Sensibility easily, pre-set the weight, volume,
Infrared counting
size and location in respect of the metal Articles and eliminate the false alarming for the coin, key, jewelry, leather belt button, etc.
Alarm settings

The intelligent counter can calculate the number of the Passenger flow and the times of alarming. eight kind of alarm sound

Allocation of six mutual over-lapping detecting areas, Simultaneous alarming

Detecting areas
from multi-areas and accurately ascertaining the location Of the metal articles according to the layout of the metal articles.
Operating Environment
Operation temperature/Humidity
5°C-40°C / 0%-90%(non-condensing)
Storage temperature/Humidity
-20°C-55°C / 0%-98%(non-condensing)
Operation Power
220VAC (±10%) 50±3Hz (Optional: 100VAC, 110VAC, 120VAC, 200VAC)

Product Dimensional Drawing

Important Sizes :

Outer frame Size: 2220* 820 * 500mm (L × W × H)

Inner frame Size: 2000* 700 * 500mm(L x W x H)
